Screenshots Stellar Migrator for Exchange

Live Exchange
Office 365

Step 1
General settings of the Job

A migration job involves migrating mailboxes, which include emails, calendars, contacts, and other data, from one Exchange server or platform to another. Configuring General Settings is the first step to create a migration job. In this step, you need to provide a name for your migration job and choose the source and target server types. The source server is where you are migrating data from, and the target server is where the data will go.
Step 2
Select Mailbox Type

In the Mailbox Types step you need to select which mailbox type you want to migrate. You will have the option to migrate primary mailboxes, archive mailboxes, and public folders separately or together
Step 3
Connect to Source Exchange Server

You need to connect the software to the server you want to migrate the mailboxes form. You can use Autodiscover option and connect directly to the source Exchange Server. Or, you can manually enter the details of the server, like IP address/ Exchange Server name, Email address, and Password.
Step 4
Preview source mailboxes

In the next step, you will see a list of mailboxes obtained from the source server. If there are more than 100 mailboxes, choose the option "Load Mailboxes Using CSV" and upload a CSV file with the remaining mailboxes.
Step 5
Connect to Target Server

Step 5 In the Connect Target tab you need to connect the destination Exchange server. To do this you need have admin credentials and impersonate rights.
Step 6
Perview Target Mailboxes

You will then see the mailboxes in the destination server. Again, if you have more than 100 mailboxes you can select the Load Mailboxes using CSV to view all the mailboxes.
Step 7
Map Mailboxes

If you did not enable the auto mapping feature you can manually map the mailboxes on the source server to the destination server.
Step 8
Set a date filter

Step 7: In the next step you can apply a date filter on the mailboxes and select the mailboxes for migration within a date range.
Step 9
Select the folder type

Then, you need to select the folder types you want to migrate. Using this you can exclude unnecessary or irrelevant folders and make sure that only the required data is migrated.
Step 10
Set Max concurrency

In the next step, you need to select, how many mailboxes you want to migrate simultaneously. You can select up to 10 mailboxes. However, this can affect the speed of migration.
Step 11
Job summary

In the next step, see the job summary and confirm all the details before starting with the migration. If you want to change anything, select that section and make the changes.
Step 12
Initiate Migration

Click Finish to create the job and then click Start in the JOB ribbon to start migration process. You can pause the migration any time with the Pause button in the JOB ribbon.
Step 13
View the Progress report

If you need, you can export the Job Progress and Mailbox Progress reports from a dashboard. These reports are used for tracking the migration, because they provide an overview of the job.
Step 14
Migration completed

After completing the migration, the action field in the job progress section of the right panel will change from Migrate to Don't Migrate. If the job fails to migrate, it will remain in the Migrate state, allowing you to attempt the migration again without making repeated changes.

Step 1
Select Hosted Exchange and Enter login details

Select Hosted Exchange to export mailboxes from an online EDB file. Select Connect to Single Mailbox or Connect to Single Mailbox from Connection Options
Step 2
Enter Admin Email and Server Name

Enter Admin and Server Name (for Exchange 5.5, 2000, 2003, 2007) or tick "Exchange Server 2010 and higher" checkbox to enter Admin Email, Server Name and Password (for MS Exchange 2010, 2013, 2016, and 2019). Click OK.
Step 3
Check Connected/Disconnected Mailbox Status

After establishing the connection with Exchange Server, Next window displays list of connected and disconnected mailboxes. Click "OK" to proceed.
Step 4
Check the Preview of all Mailboxes

Check the preview of all mailbox items- Emails, Calendars, Contacts etc.
Step 5
Select “Save as PST”

Click Save from Home Ribbon and Select Save as PST option. Click "Next" to proceed.

Step 1
General settings

To configuring General Settings of the migration job, you need to provide a name for your migration job and choose the source and target server types. The source server is where you are migrating data from, and the target server is where the data will
Step 2
Select Mailbox Type

In the Mailbox Types step you need to select which mailbox type you want to migrate. You will have the option to migrate primary mailboxes, archive mailboxes, and public folders separately or together.
Step 3.1
Connect to the source

You need to connect the software to the server you want to migrate the mailboxes form. You can use Autodiscover option and connect directly to the source Exchange Server. If you use auto-registration click Log in as Microsoft 365 Global admin to load the Entra ID sign-in page.
Step 3.2
Manual registration

The manual registration requires you to manually input the necessary connection details to authenticate and establish a connection with the source server.
Step 4
Preview the source mailboxes

In the next step you will see a list of mailboxes from the source server. If there are more than 100 mailboxes, choose "Load Mailboxes Using CSV" and upload a CSV file if you want to view the remaining mailboxes.
Step 5
Connect the target server

When the target server is Microsoft 365, you’ll need to authenticate to establish a secure connection. This uses modern authentication with ADAL (Active Directory Authentication Library) and OAuth 2.0 to safely access and transfer data from Microsoft 365 to the target environment. There are two methods to register the target connection: Auto registration and Manual registration.
Step 6
Preview the mailboxes on the Target server

You will then see the mailboxes in the destination server. Again, if you have more than 100 mailboxes you can select the Load Mailboxes using CSV to view all the mailboxes.
Step 7
Manually map the mailboxes if required

If the user names did not match you can manually map the mailboxes that are unmapped
Step 8
Set the date filter

In the next step you can apply a date filter on the mailboxes and select the mailboxes for migration within a date range.
Step 9
Select the folder types

Then, you need to select the folder types you want to migrate. Using this you can exclude unnecessary or irrelevant folders and make sure that only the required data is migrated.
Step 10
Set Max concurrency

In the next step, you need to select, how many mailboxes you want to migrate simultaneously. You can select up to 10 mailboxes. However, this can affect the speed of migration.
Step 11
Preview the job summary

In the next step, see the job summary and confirm all the details before starting with the migration. If you want to change anything, select that section and make the changes.
Step 12
Initiate Migration

Click Finish to create the job and then click Start in the JOB ribbon to start migration process. You can pause the migration any time with the Pause button in the JOB ribbon.
Step 13
View and save the progress report

If you need, you can export the Job Progress and Mailbox Progress reports from a dashboard. These reports are used for tracking the migration, because they provide an overview of the job.
Step 14
Job completion

After completing the migration, the action field in the job progress section of the right panel will change from Migrate to Don't Migrate. If the job fails to migrate, it will remain in the Migrate state, allowing you to attempt the migration again without making repeated changes.

Étape 1
Sélectionnez Hosted Exchange et entrez vos données de connexion.

Sélectionnez Hosted Exchange pour exporter des boîtes aux lettres à partir d'un fichier EDB en ligne. Sélectionnez Connecter à une seule boîte aux lettres ou Connecter à une seule boîte aux lettres dans les options de connexion.
Étape 2
Saisissez l'adresse électronique de l'administrateur et le nom du serveur

Saisissez le courriel de l'administrateur et le nom du serveur (pour Exchange 5.5, 2000, 2003, 2007) ou cochez la case "Exchange Server 2010 and higher" pour saisir le courriel de l'administrateur, le nom du serveur et le mot de passe (pour MS Exchange 2010, 2013, 2016 et 2019). Cliquez sur OK.
Étape 3
Vérifier l'état de la boîte aux lettres connectée/déconnectée

Une fois la connexion à Exchange Server établie, une liste des boîtes aux lettres connectées et déconnectées s'affiche dans la fenêtre suivante. Cliquez sur "OK" pour continuer.
Étape 4
Vérifier l'aperçu de toutes les boîtes aux lettres

Vérifiez l'aperçu de toutes les boîtes aux lettres - courriels, calendrier, contacts, etc.
Étape 5
Sélectionnez "Enregistrer sous PST".

Cliquez sur Enregistrer dans le ruban Démarrer et sélectionnez l'option Enregistrer sous PST. Cliquez sur "Suivant" pour continuer.

Passo 1
Selezioni Hosted Exchange e inserisca i suoi dati di accesso.

Selezioni Hosted Exchange per esportare le caselle postali da un file EDB online. Selezioni Connetti a una singola casella postale o Connetti a una singola casella postale dalle opzioni di connessione.
Passo 2
Inserisca l'e-mail dell'amministratore e il nome del server

Inserisca il nome dell'amministratore e del server (per Exchange 5.5, 2000, 2003, 2007) o selezioni la casella di controllo "Exchange Server 2010 e superiore" per inserire l'e-mail dell'amministratore, il nome del server e la password (per MS Exchange 2010, 2013, 2016 e 2019). Clicchi su OK.
Passo 3
Controlli lo stato della mailbox collegata/disconnessa.

Una volta stabilita la connessione a Exchange Server, nella finestra successiva viene visualizzato un elenco di caselle postali collegate e scollegate. Clicchi su "OK" per continuare.
Passo 4
Controlli l'anteprima di tutte le cassette postali

Controlli l'anteprima di tutte le caselle di posta elettronica - e-mail, calendario, contatti, ecc.
Passo 5
Selezionare "Salva come PST".

Clicchi su Salva nella barra multifunzione Avvio e selezioni l'opzione Salva come PST. Clicchi su "Avanti" per continuare.

Paso 1
Seleccione Hosted Exchange e introduzca sus datos de acceso.

Seleccione Hosted Exchange para exportar buzones desde un archivo EDB en línea. Seleccione Conectarse a un único buzón o Conectarse a un único buzón en las opciones de conexión.
Paso 2
Introduzca el correo electrónico del administrador y el nombre del servidor

Introduzca el correo electrónico del administrador y el nombre del servidor (para Exchange 5.5, 2000, 2003, 2007) o marque la casilla "Exchange Server 2010 y superior" para introducir el correo electrónico del administrador, el nombre del servidor y la contraseña (para MS Exchange 2010, 2013, 2016 y 2019). Haga clic en Aceptar.
Paso 3
Comprobar el estado del buzón conectado/desconectado

Una vez establecida la conexión con Exchange Server, en la siguiente ventana aparecerá una lista de los buzones conectados y desconectados. Haga clic en "Aceptar" para continuar.
Paso 4
Comprobar la vista previa de todos los buzones

Compruebe la vista previa de todos los buzones: correos electrónicos, calendario, contactos, etc.
Paso 5
Seleccione "Guardar como PST".

Haga clic en Guardar en la cinta Inicio y seleccione la opción Guardar como PST. Haga clic en "Siguiente" para continuar.

Schritt 1
Wählen Sie Hosted Exchange und geben Sie Ihre Anmeldedaten ein.

Wählen Sie Hosted Exchange, um Postfächer aus einer Online-EDB-Datei zu exportieren. Wählen Sie Verbinden mit einem einzelnen Postfach oder Verbinden mit einem einzelnen Postfach aus den Verbindungsoptionen
Schritt 2
Admin-E-Mail und Servernamen eingeben

Geben Sie admin und den Servernamen ein (für Exchange 5.5, 2000, 2003, 2007) oder aktivieren Sie das Kontrollkästchen "Exchange Server 2010 und höher", um admin E-Mail, Servernamen und Passwort einzugeben (für MS Exchange 2010, 2013, 2016 und 2019). Klicken Sie auf OK.
Schritt 3
Prüfen Sie den Status der verbundenen/getrennten Mailbox

Sobald die Verbindung zu Exchange Server hergestellt ist, wird im nächsten Fenster eine Liste der verbundenen und nicht verbundenen Postfächer angezeigt. Klicken Sie auf "OK", um fortzufahren.
Schritt 4
Prüfen Sie die Vorschau aller Postfächer

Prüfen Sie die Vorschau aller Postfächer - E-Mails, Kalender, Kontakte, etc.
Schritt 5
Wählen Sie "Als PST speichern".

Klicken Sie im Menüband Start auf Speichern und wählen Sie die Option Als PST speichern. Klicken Sie auf "Weiter", um fortzufahren.
